A Entity Component System (ECS) for Unity 6.3 that gives you archetype storage, chunked components, type-safe queries, deferred command buffers, transient events and a Burst-friendly system scheduler, all without the DOTS dependency.

• Archetype chunk storage: Each unique ComponentMask is a chunk of NativeArray<Entity> and one NativeList<T> per component type. The spec is followed precisely (Bevy-like). Memory is allocated once per archetype and reused as entities move between archetypes.
• 256 component types max: ComponentMask is a single fixed ulong[4] (a readonly struct with [StructLayout(LayoutKind.Sequential)]), the 256-bit cap matches the spec exactly and keeps the mask check branchless.
• Type-safe queries: QueryBuilder.With<T>().Without<U>().WithAny<A,B>().Build<T...>() returns a ref struct QueryIterator<T...> that walks archetypes, chunks, then rows. ref access into components (no defensive copies) and a Count / MatchingArchetypeCount snapshot — all with structural-version checks that throw on mutations during iteration.
• Deferred command buffers: CommandBuffer records CreateEntity / AddComponent / RemoveComponent / SetComponent / DestroyEntity / DestroyEntitiesWith<T> and is played back by a CommandBufferSystem at the end of Phase.PostUpdate. Provisional entities (created in the same buffer, used in subsequent commands within the buffer) use the high bit of Entity.Index as a marker and are resolved to real entities on Playback.
• Transient events: EventQueue<T> is double-buffered. EventWriter<T>.Send is one-frame-latent; SendImmediate is the same-frame escape hatch. Readers drain via EventReader<T> (foreach, AsNativeArray for jobs, Count, MoveNext / Current).
• Reflection is startup-only: system discovery, attribute reads ([UpdateInPhase], [UpdateAfter], [UpdateBefore], [DisableByDefault]), and ComponentRegistry.IdOf<T>() all run during SystemScheduler.Initialize and WorldBootstrap.Awake. The hot path reads only cached lists/dicts. No reflection in Tick or Update or MoveNext.
• Burst + Jobs + URP: jobs (IJobParallelFor, IJob) for the heavy lifting; Graphics.DrawMeshInstanced for the rendering sample; RenderPipelineManager.beginContextRendering for the URP-native PreRender hook.
• 85 EditMode tests pass (7 phases: Foundations, Single-Archetype Storage, Multi-Archetype + Queries, System Scheduler, Command Buffer, Events, Integration Benchmarks).

What Is an ECS?

An Entity Component System (ECS) separates what exists (entities), what data it carries (components), and what logic runs on that data (systems). Instead of deep inheritance trees or fat MonoBehaviour classes that mix transform, health, AI, and rendering in one object, an ECS stores each concern as a small unmanaged struct and runs systems that iterate matching entities in tight loops.

That layout is data-oriented: components of the same type live contiguously in memory (Structure of Arrays), so a system that updates 50,000 velocities reads a sequential buffer, friendly to CPU caches and easy to hand off to Burst jobs. Gameplay code becomes “for every entity that has Position and Velocity, update position” rather than “for every EnemyController, call Update().”

Core concepts in APECS:

flowchart TB
  subgraph World
    SS[SparseSet
entity → location]
    AS[ArchetypeStorage]
  end

  subgraph Archetype["Archetype (Position + Velocity)"]
    C0[Chunk 0
128 entities max]
    C1[Chunk 1]
    PS[ComponentStore Position]
    VS[ComponentStore Velocity]
  end

  E1[Entity 42] --> SS
  SS --> C0
  C0 --> PS
  C0 --> VS

  SYS[MovementSystem] -->|Query With Position, Velocity| AS
  AS --> Archetype

Why not classic Unity components? A MonoBehaviour per object allocates managed memory, scatters fields across the heap, and virtualizes Update() per instance. At scale (tens of thousands of agents or particles), that cost dominates. ECS inverts the loop: one system, one hot path, thousands of entities processed with predictable memory access. APECS still coexists with MonoBehaviours, WorldBootstrap is a normal component that ticks systems from Unity’s game loop; you choose how much of the project lives in ECS vs traditional scripts.

What Sets APECS Apart?

APECS stands for Archetypal Parallel Entity Component System. Compared to other ECS approaches you might know:

What is distinctive about APECS specifically:

• Fixed 256-type cap: ComponentMask is four ulongs (fixed ulong[4]). Mask tests are branchless; no dynamic bitsets on the hot path.
• Generational entities: destroying an entity bumps its generation; stale handles fail IsAlive without touching freed memory.
• Structural version guard: query iterators snapshot World.StructuralVersion and throw if the world mutates mid-iteration, pushing you toward deferred CommandBuffer usage.
• Provisional entities: commands recorded in the same buffer can reference entities not yet created; Playback resolves them in order.
• Transient double-buffered events: EventWriter / EventReader with one-frame latency by default; SendImmediate for same-frame escape hatches.
• Reflection only at startup: system discovery, attribute ordering, and ComponentRegistry.IdOf<T>() run once in Initialize; Tick and query iteration use cached lists only.

flowchart LR
  subgraph UnityLoop["Unity game loop"]
    WB[WorldBootstrap]
    WB --> Pre[PreUpdate]
    WB --> Up[Update]
    WB --> Post[PostUpdate]
    WB --> Fix[FixedUpdate]
    WB --> Late[LateUpdate]
    WB --> PR[PreRender URP]
  end

  subgraph APECS["APECS runtime"]
    SS[SystemScheduler]
    CB[CommandBufferSystem]
    W[World]
  end

  Pre --> SS
  Up --> SS
  Post --> SS
  Post --> CB
  Fix --> SS
  Late --> SS
  PR --> SS
  SS --> W
  CB -->|Playback| W

The design goal is a small, readable codebase you can read in an afternoon.

Why Not Use Unity DOTS?

Unity DOTS (Data-Oriented Technology Stack) centers on the com.unity.entities package: baked subscenes, entity hierarchies, blob assets, netcode ghosts, source-generated systems, and deep integration with the Entities editor workflow. It is the right choice when you are building a DOTS-first project and want Unity’s long-term data-oriented roadmap (NetCode, ECS authoring, conversion pipelines).

APECS deliberately does not depend on Entities. It targets a different trade-off:

Choose Unity DOTS when you need official baking/subscenes, Entities Graphics, NetCode or you are committing to Unity’s ECS authoring tools for the whole project.

Choose APECS when you want archetype storage and Burst-friendly iteration without pulling in com.unity.entities, when you prefer a transparent, short implementation you can extend or fork or when you need ECS for one subsystem (particles, crowds, simulation) inside an otherwise classic Unity project.

Both can use Burst, Jobs and NativeArray. APECS is not “anti-performance”; it is anti-lock-in to the full Entities ecosystem. You keep Unity’s familiar Update / FixedUpdate / URP render callbacks. APECS systems plug into those phases via [UpdateInPhase] instead of replacing Unity’s player loop entirely.

What Can Be Used For

• Data-oriented game architecture for Unity projects that need ECS without committing to DOTS / Entities package.
• High-throughput simulations — particles, agents, boids — running into the hundreds of thousands on mid-range hardware thanks to chunked archetypes and Burst-compiled jobs.
• Custom engines inside an existing Unity project — APECS ships as a single asmdef (FronkonGames.APECS) and doesn’t replace the standard MonoBehaviour loop; WorldBootstrap is a regular MonoBehaviour that ticks systems from the Unity game loop.
• URP / Built-in / HDRP compatible — the package is render-pipeline agnostic; sample code in Samples~/ParticleSimulation/ uses Graphics.DrawMeshInstanced for one-draw-call rendering.
• Teaching / learning ECS — the codebase is short, fully tested, and the design follows the public spec (DEVELOPMENT.md) closely. Easy to read top-to-bottom.

What Is NOT

• DOTS / com.unity.entities. The Packages/manifest.json deliberately does not include com.unity.entities. Everything is Unity.Collections / Unity.Mathematics / Unity.Jobs / Unity.Burst only. If you want Entities’ archetypes, jobs, baking, or scene conversion, use Entities.
• A job system library — APECS uses Unity’s Unity.Jobs (IJob, IJobParallelFor, IJobParallelForBatch) but doesn’t abstract them. If you want a more sophisticated job graph, look at com.unity.jobs or Entities’ system update group.
• A scene baking / subscene pipeline. There is no Editor-side baking; archetypes are created lazily on the first world.CreateEntity(mask) call. The user defines masks manually (typically at bootstrap time).
• A networking solution. Single-process only — there is no serialisation, no RPCs, no ghost replication. The system intentionally stops at “fast deterministic local simulation”.
• A visual / editor / inspector framework. No custom inspector, no scene gizmos, no Entity Debugger. The two Samples~/ projects show how to render (URP DrawMeshInstanced) and to spawn agents, but rendering is your responsibility.

Installation

Requirements:

• Unity 6000.3 LTS or newer.
• The FronkonGames.APECS package already includes the URP render pipeline integration. The package works with the URP, Built-in, and HDRP render pipelines (no render-pipeline-specific code in the runtime).

Installation (as a local package in this repo):

1. Open this repository as a Unity project.
2. The Assets/FronkonGames/APECS/ folder is the runtime source. The asmdef (FronkonGames.APECS.asmdef) is already configured with allowUnsafeCode: true (needed for the fixed ulong Mask[4]), and the Tests/ folder has a separate APECS.Tests.asmdef that’s only included in test mode.
3. To consume APECS from a different Unity project, add the line below to that project’s Packages/manifest.json and Unity will pick it up on the next refresh:

   "com.fronkongames.apecs": "file:../../path/to/APECS"

4. No additional setup is required — the package is ready to use out of the box.

How To Use

The WorldBootstrap component is the central entry point. It owns the World, the SystemScheduler, the CommandBufferSystem, the WorldTime resource, and a Resources container; it hooks into the Unity game loop and the URP render loop to tick systems on the right phase.

Create an empty GameObject and add the WorldBootstrap component (Fronkon Games APECS World Bootstrap).

World

A World is the top-level ECS container for one simulation. It holds every live entity, every archetype and chunk, shared resources, event queues, and the link to the command-buffer flush system.

You typically create one world per game session (or one per logical simulation). WorldBootstrap creates it for you in a scene, or you can construct it manually.

Use the world to register component types, spawn and destroy entities, read and write components, run queries, and coordinate systems. Nothing in APECS stores entity data outside a world, if you need two independent simulations (e.g. main game + replay), use two worlds.

using FronkonGames.APECS;
using Unity.Mathematics;

World world = new World("MyGame");

// Register a component factory once, at bootstrap. Required for every T that
// will appear in any archetype mask, the storage subsystem uses these to
// materialise a fresh IComponentStore for a new archetype.
world.RegisterStoreFactory<Position>();
world.RegisterStoreFactory<Velocity>();
world.RegisterStoreFactory<Health>();

Systems

In ECS, a system is a unit of behaviour: code that runs once per tick and operates on entities matching a query. Systems do not own entity data, they read and write components stored in the world. APECS systems implement ISystem or inherit SystemBase, are tagged with [UpdateInPhase], and are ticked by SystemScheduler (via WorldBootstrap) on Unity’s update loop.

The subsections below walk through what systems use every frame: creating entities, reading and writing components, iterating with queries, deferring structural changes, and passing events. Further down you will find the full runtime API reference for each type (World, Entity, ComponentMask, and the rest).

using FronkonGames.APECS;
using Unity.Mathematics;

// Discovered automatically when [UpdateInPhase] is present and autoDiscoverSystems = true.
[UpdateInPhase(Phase.Update)]
public sealed class MovementSystem : SystemBase
{
  protected override void Update()
  {
    // Query all entities with Position + Velocity; mutate components in place.
    var iter = Query()
      .With<Position>()
      .With<Velocity>()
      .Build<Position, Velocity>();

    while (iter.MoveNext())
    {
      ref Position p = ref iter.Current.t;
      ref Velocity v = ref iter.Current.u;
      p.Value += v.Value * DeltaTime;
    }

    // Do not DestroyEntity or AddComponent here while iter may still be open.
    // Record structural work into Commands — flushed at Phase.PostUpdate.
    // Commands.DestroyEntity(dead);
  }
}

Entities

An entity is a lightweight ID (index + generation), not a class instance. Creating one allocates a slot in the world’s SparseSet and places it in the archetype that matches the component mask you pass in, the set of component types that entity will have. The mask defines the memory layout, all entities with the same mask share one archetype and are stored together in chunks for cache-friendly iteration.

Call world.CreateEntity(mask) when you need a new object in the simulation. The first use of a mask lazily creates the archetype and its component stores (which is why you must RegisterStoreFactory<T>() for every type in the mask beforehand).

To remove an entity, call world.DestroyEntity(e), the handle becomes stale immediately because the generation bumps.

// Create an entity in a specific archetype. Lazily materialises the archetype
// (and its component stores) on first use.
var e = world.CreateEntity(ComponentMask.Of<Position, Velocity>());

// Or, with an existing mask:
ComponentMask moving = ComponentMask.Of<Position, Velocity, Health>();
var e2 = world.CreateEntity(moving);

Add And Read Components

Components are plain unmanaged structs, data only, no behaviour. Each entity carries the component types defined by its archetype mask; you can read and write them through the world as long as the entity is alive and actually has that type.

Use SetComponent to write a value, GetComponent to read a copy, and GetComponentRef when you want to mutate in place without allocating or copying (the usual choice in hot loops).

HasComponent checks membership without throwing. IsAlive validates the entity handle first.

Writing a component the entity does not have throws, add it with AddComponent (a structural change that migrates the entity to a new archetype) instead of SetComponent.

world.SetComponent(e, new Position { Value = new float3(0, 0, 0) });
world.SetComponent(e, new Velocity { Value = new float3(1, 0, 0) });

// GetComponent returns a copy. For read-only access through a ref, use GetComponentRef.
ref Position p = ref world.GetComponentRef<Position>(e);
p.Value += float3.zero; // mutate in place, no copy

// Multi-component batched read on the same entity.
bool alive = world.IsAlive(e);
bool has = world.HasComponent<Health>(e);

Query Entities

Queries are how systems process many entities at once. Instead of tracking entity lists yourself, you describe a filter (With, Without, WithAny) and APECS walks every matching archetype and chunk, yielding each live row with direct ref access to its components, no boxing, no per-entity dictionary lookups.

Start from world.Query(), chain filter rules, then call Build<T...>() with the component types you want to read or mutate (up to eight). The returned QueryIterator is a ref struct: stack-only, zero allocation, and safe to use in tight loops or to feed Burst jobs via GetComponentArray. Do not create or destroy entities, or add/remove components, while iterating, the iterator checks StructuralVersion and throws if the world changed mid-walk. Defer those changes to a CommandBuffer instead.

// Build a query that matches archetypes containing Position + Velocity but not Health.
var iter = world.Query()
  .With<Position>()
  .With<Velocity>()
  .Without<Health>()
  .Build<Position, Velocity>();

// foreach via the ref-struct enumerator. entry.t is `ref Position`, entry.u is `ref Velocity`.
while (iter.MoveNext())
{
  ref var p = ref iter.Current.t;
  ref var v = ref iter.Current.u;
  p.Value += v.Value * UnityEngine.Time.deltaTime;
}

QueryEntry<T...> exposes each requested component as a ref-typed property (t, u, v, w, x, y, z, a for 1-8 components respectively). Use these directly in the inner loop body — no copy, no array indexing.

Defer Structural Changes

Structural changes alter the shape of the world: creating or destroying entities, or adding/removing component types (which moves an entity to a different archetype). Each one bumps StructuralVersion and can invalidate open query iterators. Mutating structure while iterating is therefore unsafe — record the work instead and apply it later.

A CommandBuffer queues those mutations as ordered commands. Systems obtain their own buffer via CommandBufferSystem.GetBuffer(this) (or Commands on SystemBase). Commands recorded in the same buffer can reference provisional entities created earlier in that buffer; Playback resolves them to real handles before applying the rest. By default, CommandBufferSystem flushes every buffer at the end of Phase.PostUpdate, so gameplay systems can iterate safely all frame and structural edits land in one consistent batch.

// Systems that mutate structure during iteration should record into their Commands
// buffer, not the world directly. The CommandBufferSystem plays every buffer back
// at the end of Phase.PostUpdate.
var buffer = world.CommandBufferSystem.GetBuffer(this);
buffer.CreateEntity(ComponentMask.Of<Position, Velocity>());
buffer.DestroyEntity(e);

Send And Read Events

Events are transient, typed messages between systems, spawn requests, damage notifications, input pulses, not long-lived component data. Each event type gets a double-buffered EventQueue<T> on the world.

Writers append to one side, at the start of the next Update, FixedUpdate, or LateUpdate tick the scheduler swaps buffers so readers drain what was sent last phase.

From a SystemBase subclass, use GetEventWriter<T>() to publish and GetEventReader<T>() to consume.

Send is the default: one frame of latency, safe when producer and consumer run in the same phase group.

SendImmediate writes straight to the readable buffer for same-frame delivery when you accept tighter coupling. Events are not stored on entities, if something must persist, use a component or a world resource instead.

// Writer. Send is one-frame-latent (visible to next-phase readers). SendImmediate
// bypasses the buffer for same-frame use.
GetEventWriter<DamageEvent>().Send(new DamageEvent { Amount = 10 });
GetEventWriter<DamageEvent>().SendImmediate(new DamageEvent { Amount = 99 });

// Reader (one frame later in the next Update/FixedUpdate/LateUpdate tick, after
// the scheduler has called SwapAllEventQueues).
var reader = GetEventReader<DamageEvent>();
while (reader.MoveNext())
{
  DamageEvent evt = reader.Current;
  Debug.Log($"damage: {evt.Amount}");
}

Snapshot The World

Sometimes you need a read-only picture of the simulation (for debug UI, tests or logging) without walking a typed query. The world exposes a few cheap counters and introspection hooks for that.

EntityCount is the number of live handles. StructuralVersion increments on every structural change, query iterators snapshot it at creation time and compare on each MoveNext, which is why this value is useful when debugging “iterator invalidated” errors.

ArchetypeStorage lists every materialised archetype with its mask, entity count, and chunk count — handy to verify that masks are splitting entities the way you expect. These APIs are for diagnostics and tooling; gameplay systems should prefer Query for iteration.

// EntityCount / StructuralVersion are useful for sanity checks and for the
// "structural mutation during iteration" guard.
Debug.Log($"alive={world.EntityCount} version={world.StructuralVersion}");

// Iterate every archetype:
for (int a = 0; a < world.ArchetypeStorage.ArchetypeCount; a++)
{
  var arch = world.ArchetypeStorage.All[a];
  Debug.Log($"archetype {a}: mask={arch.Mask} entities={arch.EntityCount} chunks={arch.ChunkCount}");
}

ComponentMask

A ComponentMask describes which component types an entity has. It is a 256-bit bitset (fixed ulong[4]), one bit per registered component type, stored as a small unmanaged struct. Every entity belongs to exactly one archetype per mask; entities that share the same mask are stored together in the same chunks.

You use masks when creating entities (CreateEntity(mask)), building queries (filters compare against archetype masks), and recording command-buffer commands. Factory helpers like ComponentMask.Of<Position, Velocity>() register types in ComponentRegistry on first use and set the corresponding bits. HasAll, HasAny, and HasNone compare masks in branchless word operations, useful inside query filters and custom matching logic. When you AddComponent or RemoveComponent, the world derives a new mask from the old one (Set / Unset) and migrates the entity to the matching archetype.

using FronkonGames.APECS;

// Build from component types (registers each type in ComponentRegistry on first use).
ComponentMask moving = ComponentMask.Of<Position, Velocity>();
ComponentMask combat  = ComponentMask.Of<Position, Velocity, Health>();

// Or assemble manually from stable IDs.
ComponentMask custom = default;
custom.Set(ComponentRegistry.IdOf<Position>());
custom.Set(ComponentRegistry.IdOf<Velocity>());

// Membership tests between masks.
ComponentMask required = ComponentMask.Of<Position>();
ComponentMask excluded = ComponentMask.Of<Health>();

bool matches = moving.HasAll(required);   // true — moving includes Position
bool blocked = moving.HasAny(excluded);   // false — moving has no Health
bool clean   = moving.HasNone(excluded);  // true — no excluded types present

// Use when creating entities or recording commands.
Entity e = world.CreateEntity(ComponentMask.Of<Position, Velocity>());

// Derive a new mask (e.g. before AddComponent / RemoveComponent internally).
ComponentMask withHealth = moving;
withHealth.Set(ComponentRegistry.IdOf<Health>());

ComponentMask withoutVel = moving;
withoutVel.Unset(ComponentRegistry.IdOf<Velocity>());

SparseSet

The SparseSet is the world’s entity table. It maps each live entity index to a generation (for stale-handle detection) and an EntityRecord (archetype id, chunk index, row). When you call world.CreateEntity, the world allocates an ID from the sparse set and registers where that entity lives in archetype storage; every GetComponentRef lookup goes through this map first.

You rarely touch SparseSet directly in gameplay code, World.IsAlive, CreateEntity, and DestroyEntity wrap it. It is useful to understand for debugging, tests, and custom tooling. Create hands out reusable indices from a free list; Destroy bumps the generation so old handles fail IsAlive without freeing memory unsafely. Index 0 is reserved for Entity.Null.

using FronkonGames.APECS;

SparseSet set = new SparseSet();

// Liveness: allocate an ID (generation starts at 1 for a fresh index).
Entity e = set.Create();                    // e.g. Entity(idx:1 gen:1)
Debug.Log(set.Count);                       // 1

// Location: where the entity lives inside its archetype (written by World).
set.Set(e, new EntityRecord
{
  ArchetypeId = 1,
  ChunkIndex = 0,
  Row = 0,
});

if (set.TryGet(e, out EntityRecord loc))
  Debug.Log($"archetype={loc.ArchetypeId} chunk={loc.ChunkIndex} row={loc.Row}");

// Destroy: generation bumps; stale copies of e no longer pass IsAlive.
Entity stale = e;
set.Destroy(e);
Debug.Log(set.IsAlive(stale)); // false
Debug.Log(set.IsAlive(e));     // false

Archetype + ArchetypeChunk

An archetype is the storage bucket for all entities that share the same component mask. It owns one ComponentStore<T> per component type and a list of ArchetypeChunk blocks. An ArchetypeChunk is a fixed slab of up to 128 entities (ArchetypeChunk.Capacity), each row storing an Entity handle; matching component data for that row lives at the same index in each store (Structure of Arrays).

When the last chunk fills up, the archetype allocates another chunk and grows the stores. Add appends to the tail chunk; Remove uses swap-back (the last live row moves into the vacated slot) so arrays stay dense. You normally reach archetypes through world.ArchetypeStorage after CreateEntity, queries iterate them automatically; direct access is for debugging, jobs, or custom tooling.

using FronkonGames.APECS;

// Two entities with the same mask share one archetype.
Entity a = world.CreateEntity(ComponentMask.Of<Position, Velocity>());
Entity b = world.CreateEntity(ComponentMask.Of<Position, Velocity>());

Archetype arch = world.ArchetypeStorage.All[0];
Debug.Log($"mask={arch.Mask} entities={arch.EntityCount} chunks={arch.ChunkCount}");

// Each chunk tracks dense entity rows [0..count).
ArchetypeChunk chunk = arch.Chunks[0];
Debug.Log($"chunk occupancy={chunk.count}/{ArchetypeChunk.Capacity} full={chunk.IsFull}");

// Component data for row r lives at (chunkIndex, row) in each store.
int posId = ComponentRegistry.IdOf<Position>();
var posStore = (ComponentStore<Position>)arch.GetStore(posId);
ref Position p = ref posStore.GetRef(chunkIndex: 0, row: 0);
p.Value += new float3(1, 0, 0);

ArchetypeStorage

ArchetypeStorage is the world’s registry of archetypes. It maps each distinct ComponentMask to one Archetype instance and assigns stable numeric IDs. Archetypes are materialised lazily: the first time a mask is used (via world.CreateEntity or GetOrCreate), storage creates the archetype and builds a ComponentStore<T> for every bit set in the mask using the factories you registered with RegisterStoreFactory<T>().

Gameplay code usually goes through World, but world.ArchetypeStorage is the right entry point for introspection, custom iterators, and tests. GetOrCreate(mask) returns an existing bucket or allocates a new one. All lists every archetype in creation order; GetById resolves the ID stored in each entity’s EntityRecord. As masks proliferate (many component combinations), archetype count grows, that is normal and expected.

using FronkonGames.APECS;

// Creating entities implicitly calls GetOrCreate for each new mask.
Entity mover = world.CreateEntity(ComponentMask.Of<Position, Velocity>());
Entity static_ = world.CreateEntity(ComponentMask.Of<Position>());

ArchetypeStorage storage = world.ArchetypeStorage;
Debug.Log($"archetypes={storage.ArchetypeCount}");   // 2 distinct masks

// Lookup by mask (same instance on repeated calls).
ComponentMask moving = ComponentMask.Of<Position, Velocity>();
Archetype arch = storage.GetOrCreate(moving);
Debug.Log(arch.EntityCount);

// Lookup by stable id (from EntityRecord after CreateEntity).
if (world.SparseSet.TryGet(mover, out EntityRecord rec))
{
  Archetype byId = storage.GetById(rec.ArchetypeId);
  Debug.Log(byId.Mask.HasAll(moving));
}

// Walk everything (debug / benchmarks).
for (int i = 0; i < storage.ArchetypeCount; i++)
  Debug.Log(storage.All[i].EntityCount);

IComponentStore + ComponentStore

Each component type inside an archetype is backed by a ComponentStore<T>: a NativeList<T> laid out in chunk-major order. Row j in chunk i lives at index i * ArchetypeChunk.Capacity + j, so all Position values for a chunk sit contiguously in memory (Structure of Arrays). IComponentStore is the non-generic interface the archetype uses for GrowChunk, swap-back RemoveAt, and MoveToChunk during entity migration.

Normal gameplay goes through world.SetComponent / GetComponentRef, which resolve (chunk, row) via the sparse set. Reach stores directly when writing Burst jobs (GetChunkArray returns a NativeArray<T> slice sized to live rows), custom iterators, or archetype introspection. One store exists per component type per archetype, not per entity.

using FronkonGames.APECS;
using Unity.Mathematics;
using Unity.Collections;

Entity e = world.CreateEntity(ComponentMask.Of<Position, Velocity>());
world.SetComponent(e, new Position { Value = float3.zero });

// Resolve store from the entity's archetype.
world.SparseSet.TryGet(e, out EntityRecord rec);
Archetype arch = world.ArchetypeStorage.GetById(rec.ArchetypeId);
var posStore = (ComponentStore<Position>)arch.GetStore(ComponentRegistry.IdOf<Position>());

// Random access by (chunk, row).
ref Position p = ref posStore.GetRef(rec.ChunkIndex, rec.Row);
p.Value.x += 1f;

// Dense slice for jobs: only live rows [0..chunk.count).
ArchetypeChunk chunk = arch.Chunks[rec.ChunkIndex];
NativeArray<Position> slice = posStore.GetChunkArray(rec.ChunkIndex, chunk.count);
// pass slice to IJobParallelFor, then dispose job dependencies as usual

QueryBuilder + QueryFilter + QueryIterator<T…>

Queries are how systems find entities without hand-rolling archetype walks. QueryBuilder is a fluent struct that accumulates a QueryFilter (With, Without, WithAny, …). Build<T...>() returns a ref struct QueryIterator<T...> (1–8 component types) that walks every matching archetype and chunk in O(archetypes × chunks).

Each MoveNext() advances to the next entity; multi-component iterators expose one ref accessor per type parameter (t, u, v, …). MoveNext throws if StructuralVersion changed since the iterator was built — record structural work in a CommandBuffer instead of mutating the world mid-iteration.

var iter = world.Query()
  .With<Position>()
  .With<Velocity>()
  .Without<Health>()
  .WithAny<SteeringTag, Wander>()
  .Build<Position, Velocity>();

while (iter.MoveNext())
{
  ref Position p = ref iter.Current.t;
  ref Velocity v = ref iter.Current.u;
  // mutate in place
}

int count = iter.Count;            // live count, re-walks the world
int archetypes = iter.MatchingArchetypeCount;
NativeArray<Position> arr = iter.GetComponentArray(archetypeIdx, chunkIdx);  // sized to Count, not Capacity

The multi-component iterator exposes one ref-typed accessor per generic parameter: t, u, v, w, x, y, z, a. QueryEntry<T...> is a ref struct that wraps these for foreach.

QueryIterator.MoveNext throws InvalidOperationException if the world StructuralVersion changed since iterator construction. This is the guard against mutations during iteration. Use a CommandBuffer if you need to mutate.

CommandBuffer + CommandBufferSystem

A CommandBuffer records deferred structural mutations: create/destroy entities, add/remove components, set components, and bulk destroy by type. Commands are stored in order and applied later during Playback, which bumps StructuralVersion once at the end. That lets systems iterate queries safely and apply all spawns/despawns in one consistent batch.

CreateEntity returns a provisional handle (high bit set on Entity.Index). Later commands in the same buffer can reference it; playback resolves provisionals to real entities before running subsequent commands. From SystemBase, use the Commands property; each system gets its own buffer via CommandBufferSystem.GetBuffer(this).

CommandBufferSystem is a normal system (default Phase.PostUpdate) that calls Playback on every registered buffer, then clears them. Assign it on the world (world.CommandBufferSystem = ...) before systems record commands, WorldBootstrap typically registers one for you.

using FronkonGames.APECS;
using Unity.Mathematics;

[UpdateInPhase(Phase.Update)]
public sealed class SpawnSystem : SystemBase
{
  protected override void Update()
  {
    var iter = Query().With<Health>().Build<Health>();
    while (iter.MoveNext())
    {
      ref Health h = ref iter.Current.Component;
      if (h.Value <= 0)
        Commands.DestroyEntity(iter.Current.entity);  // deferred, not world.DestroyEntity
    }

    // Provisional entity: usable in subsequent commands in this buffer.
    Entity bullet = Commands.CreateEntity(ComponentMask.Of<Position, Velocity>());
    Commands.SetComponent(bullet, new Position { Value = float3.zero });
    Commands.SetComponent(bullet, new Velocity { Value = new float3(0, 0, 10) });
  }
}

// CommandBufferSystem (Phase.PostUpdate) runs after Update systems:
//   Playback(world) for each buffer → real entities created → buffers cleared.

Manual playback (tests/tools):

CommandBuffer buf = new CommandBuffer(world);
Entity provisional = buf.CreateEntity(ComponentMask.Of<Position>());
buf.SetComponent(provisional, new Position { Value = float3.zero });
buf.Playback(world);   // applies to world, bumps StructuralVersion once

EventQueue + EventWriter + EventReader

Events are short-lived, typed messages — spawn requests, damage pulses, input edges — not long-lived component data. Each event type T gets a double-buffered EventQueue<T> on the world (two NativeList<T> sides). EventWriter<T> appends to the write side; EventReader<T> drains the readable side.

From SystemBase, use GetEventWriter<T>() to publish and GetEventReader<T>() to consume. Send is the default: events stay in the write buffer until the next Swap, so readers typically see last phase’s traffic. SendImmediate writes straight to the readable buffer for same-frame delivery when you accept tighter coupling.

The scheduler calls world.SwapAllEventQueues() at the start of Update, FixedUpdate, and LateUpdate only. PreUpdate, PostUpdate, PreRender, Initialization, and Teardown do not swap. Readers are stack-only ref struct iterators: use MoveNext() / Current, foreach, or AsNativeArray() for jobs. Current returns T by value — events are read-only once sent.

public struct DamageEvent { public Entity Target; public float Amount; }

[UpdateInPhase(Phase.Update)]
public sealed class CombatSystem : SystemBase
{
  protected override void Update()
  {
    GetEventWriter<DamageEvent>().Send(new DamageEvent { Target = enemy, Amount = 25 });
  }
}

[UpdateInPhase(Phase.Update)]
[UpdateAfter(typeof(CombatSystem))]
public sealed class HealthSystem : SystemBase
{
  protected override void Update()
  {
    var reader = GetEventReader<DamageEvent>();
    while (reader.MoveNext())
    {
      DamageEvent evt = reader.Current;
      ref Health h = ref World.GetComponentRef<Health>(evt.Target);
      h.Value -= evt.Amount;
    }
  }
}

Direct queue access (tests, custom hosts):

EventQueue<DamageEvent> queue = world.GetEventQueue<DamageEvent>();
queue.Send(new DamageEvent { /* ... */ });
queue.Swap();   // normally done by SystemScheduler at phase start

SystemScheduler + SystemBase + ISystem

SystemBase is the usual starting point: it wires World, Query(), Commands, event accessors, and per-tick DeltaTime / FixedDeltaTime. Subclasses override Update() (and optionally OnInitialize() / OnShutdown()). ISystem is the minimal interface (OnCreate, OnUpdate, OnDestroy, Enabled) for types that should not inherit — struct systems, thin adapters, tests.

SystemScheduler registers systems and ticks them by Phase. With autoDiscover = true, it reflects loaded assemblies for [UpdateInPhase] types, reads [UpdateAfter] / [UpdateBefore] edges, topologically sorts with Kahn’s algorithm, and invokes OnUpdate in order. Use Register<T>() / Register(ISystem) when discovery is off. Throws CircularDependencyException on dependency cycles.

Register CommandBufferSystem and assign world.CommandBufferSystem before any system uses Commands (auto-discovery picks it up like any other [UpdateInPhase] system).

// Auto-discovered when WorldBootstrap.autoDiscoverSystems = true:
[UpdateInPhase(Phase.Update)]
[UpdateAfter(typeof(MovementSystem))]
public sealed class RenderPrepSystem : SystemBase
{
  protected override void OnInitialize()
  {
    // World is assigned; register caches, subscribe to resources, etc.
  }

  protected override void Update() { /* runs each Update tick */ }
}

// Manual host (tests, headless tools):
var world = new World();
var scheduler = new SystemScheduler();
scheduler.Initialize(world, autoDiscover: false);
scheduler.Register<CommandBufferSystem>();
world.CommandBufferSystem = scheduler.GetSystem<CommandBufferSystem>();
scheduler.Register<MovementSystem>();
scheduler.Tick(Phase.Update);
scheduler.Shutdown();
scheduler.Dispose();

Public scheduler surface:

public sealed class SystemScheduler : IDisposable
{
  public void Initialize(World world, bool autoDiscover = true);
  public void Register<T>() where T : ISystem, new();
  public void Register(ISystem s);
  public void Unregister<T>() where T : ISystem;
  public T GetSystem<T>() where T : ISystem;
  public void Tick(Phase phase);
  public void Shutdown();
  public void Dispose();
}

WorldBootstrap (URP-aware)

WorldBootstrap is a MonoBehaviour entry point that owns one World and one SystemScheduler for a scene. On Awake it creates the world, sets World.Default, optionally registers WorldTime as a resource, and initializes the scheduler. Unity callbacks drive phases: Update ticks PreUpdate → Update → PostUpdate, FixedUpdate ticks FixedUpdate, LateUpdate ticks LateUpdate, and URP’s RenderPipelineManager.beginContextRendering ticks PreRender once per frame before any camera renders.

Add the component to a GameObject in your scene (execution order -1000 so it runs early). Leave autoDiscoverSystems enabled to pick up every [UpdateInPhase] system in loaded assemblies, or disable it and Register systems yourself. registerWorldTime (default on) keeps SystemBase.DeltaTime in sync with Unity’s clock.

// Inspector: worldName = "Default", autoDiscoverSystems = true, registerWorldTime = true

WorldBootstrap bootstrap = FindFirstObjectByType<WorldBootstrap>();
World world = bootstrap.World;
SystemScheduler scheduler = bootstrap.Scheduler;

// Safe from Start/Awake on other components after bootstrap Awake:
Entity player = world.CreateEntity(ComponentMask.Of<Position, Velocity>());
world.SetComponent(player, new Position { Value = float3.zero });

OnDestroy shuts down the scheduler and disposes the world. If this bootstrap owned World.Default, it clears that static on teardown.

Samples

Utilities

APECS ships a small set of focused, dependency-free helpers:

These are part of the public API; no instantiation, no extra package dependencies.

Support

Do you have any problem or any suggestions? Send an email to fronkongames@gmail.com and I’ll be happy to help you.

Remember that if you want to inform me of an error, it would help me if you sent to me the log file.
